Plotter Canon imagePROGRAF TM-240
Cod: 210974
21.690 LEI
Stoc redus (1/10)
Garanție: 12 luni
Specificații
| Printer Type | 5 Colours, 24", 4.3” operational panel |
| Print Technology | Canon Bubblejet on Demand 6 colours integrated type (6 chips per print head x 1 print head) |
| Print Resolution | 2,400 x 1,200 dpi |
| Number of Nozzles | Total: 15360 nozzles, MBK: 5120 nozzles,BK, C, M, Y: 2560 nozzles each |
| Line Accuracy | ±0.1% or less, User adjustments necessary. Printing environment and media must match those used for the adjustments. |
| Nozzle Pitch | 1,200 dpi x 2 lines |
| Ink Droplet Size | minimum 5pl per colour |
| Ink Capacity | Bundled Starter Ink: 300ml (80ml for MBK, 55mlx4 for BK, C, M, Y) |
| Sales Ink | 55ml (MBK, BK, C, M, Y) |
| Ink Type | Pigment inks: 5 colours MBK/BK/C/M/Y |
| Printer Languages | HP-GL/2, HP RTL, JPEG (Ver. JFIF 1.02), CALS G4 (submission via FTP only) |
| Standard Memory | 2GB, Expansion slot: No |
| Hard Drive | N/A |
| Print Speed | |
| CAD Drawing | Plain Paper (A1): 0:23 (Fast Economy Mode), 0:25 (Fast), 0:51 (Standard) |
| Poster | Plain Paper (A1): 0:25 (Fast Economy Mode), 0:25 (Fast),0:49 (Standard) |
| Heavy Coated Paper (A1) | 0:56 (Fast), 1:45 (Standard) |
| Media Handling | |
| Media Feed and Output | Roll Paper: One Roll, Upper-loading, Front Output |
| Cut Sheet | Upper-loading, Front Output (Manual feed using media locking lever) |
| Media Width | Roll paper: 203.2 - 610mm, Cut sheet: 210 - 610mm |
| Media Thickness | Roll/Cut: 0.07mm - 0.8mm |
| Minimum Printable Length | Roll paper: 203.2mm, Cut sheet: 279.4mm |
| Maximum Printable Length | Roll paper: 18m (varies according to the OS and application), Cut sheet: 1.6m |
| Maximum Media Roll Diameter | 150mm |
| Media Core Size | Internal diameter of roll core: 2"/3" (Optional) |
| Margins Recommended Area | Roll paper: Top: 20mm, Bottom: 3mm, Side: 3mm |
| Cut sheet (AppleAirPrint) | Top: 20mm, Bottom: 31mm, Side: 3mm |
| Cut sheet (Others) | Top: 20mm, Bottom: 20mm, Side: 3mm |
| Margins Printable Area | Roll paper: Top: 3mm, Bottom: 3mm, Side: 3mm |
| Roll paper (borderless) | Top: 0mm, Bottom: 0mm, Side: 0mm |
| Cut sheet (AppleAirPrint) | Top: 3mm, Bottom: 12.7mm, Side: 3mm |
| Cut sheet (Others) | Top: 3mm, Bottom: 20mm, Side: 3mm |
| Media Feed Capacity | Roll Paper: One roll, Cut Sheet: 1 sheet |
| Maximum Number of Delivered Prints | Standard position - 1 sheet |
| Standard Interfaces | USB A Port: N/A, USB B Port: Hi-Speed USB, |
| Ethernet | IEEE802.3ab(1000base-T), IEEE802.3u(100BASE-TX)/IEEE802.3 (10BASE-T) |
| Wireless LAN | IEEE802.11n/IEEE802.11g/IEEE802.11b |
| Consumables | |
| User Replaceable Items | Ink Tank: M: PFI-031(55ml), MBK/BK/C/Y: PFI-030(55ml) |
| Print Head | PF-06, Cutter Blade: CT-08, Maintenance Cartridge: MC-31 |
| What's in the Box | |
| Printer, 1 Print head, Power Cable, 1 Set of starter ink tanks, Installation Guide, Safety/Standard Environment leaflet, LFP Eur Address Sheet, Important Information Sheet, Notice for PosterArtist WEB | |
| Optional Items | Stand Basket (Simple Basket): SD-24 |
| 2"/3" Roll Holder | RH2-28 |
| IC Card Reader Holder | RA-02 |
