MB AM4 Gigabyte B550 GAMING X V2 ATX
Cod: 130804
2.629 LEI
Stoc epuizat (0/10)
Garanție: 36 luni
Specificații
| // CPU | |
| AMD Socket AM4, support for | AMD Ryzen™ 5000 Series/ 3rd Gen Ryzen™ and 3rd Gen Ryzen™ with Radeon™ Graphics Processors |
| Chipset | |
| AMD B550 | |
| Memory | |
| 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory | |
| AMD Ryzen™ 5000 series processors/ 3rd Generation AMD Ryzen™ | |
| Support for DDR4 4400(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules | |
| Dual channel memory architecture | |
| Onboard Graphics | |
| Integrated in the AMD Ryzen™ with Radeon™ Graphics processors | |
| 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz | |
| 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz | |
| Audio | |
| Realtek® Audio CODEC | |
| LAN | |
| Realtek® GbE LAN chip (10/100/1000 Mbit) | |
| Expansion Slots | |
| 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU | |
| 3rd Generation AMD Ryzen™ processors support PCIe 4.0 x16 mode | |
| 1 x PCI Express x16 slot (PCIEX2), integrated in the Chipset | |
| Supporting PCIe 3.0 x2 mode | |
| 3 x PCI Express x1 slots (PCIEX1_1, PCIEX1_2, PCIEX1_3) | |
| Storage Interface | |
| 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs | |
| 3rd Generation AMD Ryzen™ processors support SATA and PCIe 4.0 x4/x2 SSDs | |
| 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs | Supporting SATA and PCIe 3.0 x4/x2 SSDs |
| 4 x SATA 6Gb/s connectors | |
| Support for RAID 0, RAID 1, and RAID 10 | |
| USB | |
| 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel | |
| 3 x USB 3.2 Gen 1 ports on the back panel | |
| 1 x USB Type-C™ port with USB 3.2 Gen 1 support, available through the internal USB header | |
| 2 x USB 3.2 Gen 1 ports available through the internal USB header | |
| 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) | |
| Link | https://www.gigabyte.com/Motherboard/B550-Gaming-X-V2-rev-1x#kf |
